R548 600,00 Inc VAT
Out of stock
ENGINE
MOWER DECK
FOREFRONT™ SUSPENSION SYSTEM
The system utilizes four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.
The system utilizes four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.
| ENGINE | |
| Make | Vanguard® – Petrol |
| Model | BIG BLOCK™ EFI with Oil Guard System |
| Horsepower | 37 HP* |
| Cylinders / Displacement | 2 Cylinders V-Twin / 993 cc |
| Cooling | Air-cooled |
| PTO | Electric PTO clutch |
| Starting | Electric |
| Fuel Capacity | 42 Litres |
| MOWER | |
| Cutting width | 183 cm / 72” TRIPLE iCD™ |
| Deck Configuration | Side discharge, Rear discharge and Mulching |
| Cutting Height | 3.8 – 12.7 cm |
| Deck Construction | 3.4 mm fabricated construction, full width double top deck, 12.7 mm scuff guards, 12.7 mm leading edge, overlap welded corners |
| Mower Spindles | Cast-iron 257 mm with 30.16 mm shaft |
| Deck lift system | Foot Operated |
| SUSPENSION & DRIVE TRAIN | |
| Suspension | ForeFront™ Suspension System – Front independent with four control rods paired with large size adjustable coil over shocks and a rear swing with large adjustable coil-over shocks |
| Transmission | Independent Hydro-Gear® Commercial ZT-5400™ trans-axles with industrial oil filter and remote oil cooler |
| Drive Axles | 34.93 mm drive axles with 5 bolt wheel hubs |
| Drive Tyres | 26 x 12.00 – 12 (4 ply) |
| Caster Tyres | 13 x 6.50 – 6 (4 ply) |
| GROUND SPEED | |
| Speed – Forward | 0 – 20 km/h |
| Speed – Reverse | 0 – 10 km/h |
| DIMENSIONS | |
| Overall length | 215 cm |
| Overall width | 186 cm |
| Dry weight | 788 kg |
| OPERATOR CONTROL & COMFORT SYSTEMS | |
| Roll-Over Protection Structure | Standard, foldable with seat belt |
| Instrumentation | Fuel level gauge in each tank, hour meter, engine malfunction indicator gauge |
| Controls | Seat activated engine kill, PTO clutch safety switch, neutral and parking brake safety circuit |
| Parking Brake / Safety Circuit | Internal wet disc brake in transaxle |
| Vanguard EFI Engine | 3 Year Engine Manufacturer’s Limited Warranty |
| Deck Drive Belt (2-Belt) | 3 Year Limited / 300 hours, whichever comes first.
Parts & labour in year one. Parts only in years two and three. |
| Balance of machine | 4 Year or 500 hours Limited Warranty, whichever occurs first.Unlimited hours during the first 2 years. |
| Coil-over-shocks and all suspension related components |
5 Years / Unlimited hours. |
| Belts, Tyres, Brake Pads, Battery & Blades | 90 days. |
